Non Vision Grilles are provided by us:

Application:

Air supply or air return in air-conditioning, ventilating and heating systems.

Mounting:

Overlapped inside wall or in false ceiling by means of hidden fixing systems

Implementation:

Extruded aluminum construction. Frames with flat frontal face of 20mm or 30mm and individually adjustable blades to regulate the throw of air in the pitch of 20mm gap. Available in front horizontal back side vertical bars, both side adjustable louvers. Front horizontal with fixed bars and rear vertical with adjustable blades also available. All standard or non standard sizes, with or without collar dampers can be made.

Standard Finishes:

Natural aluminum, anodized or powder coated in standard RAL white colors.
